Model 1894 / Model 94 Repeating Rifle

"We believe that no repeating rifle system ever made will appeal to the eye and understanding of the rifleman as this will and that use will continue to warrant first impressions."        - Winchester catalog, November 1894

With only a few minor changes in its construction, the Model 1894 / Model 94 was manufactured continuously for over 100 years. This was the first lever action repeating rifle model on the market that was designed especially for smokeless powder cartridges. Note that the carbine style buttstock was changed on the carbine model in 1937, to a shotgun-style stock.

The Model 1894 was the first sporting gun to pass the 1,000,000 mark. The millionth 94 was presented in 1927 to President Calvin Coolidge. Subsequent benchmark Model 94 rifles were presented to Presidents Harry Truman (1948) and Dwight Eisenhower (1953). Serial number 2.5 million was assembled in 1961.

Please note that PGW does not manufacture stocks for special or commemorative issues of the Winchester Model 1894 due to the medallion insert cuts. Our standard stock may be adapted for use in these rifles, without the medallion adaptation; order a Late 94. We do not manufacture the shorter forearms for the Trapper model, nor do we offer stocks or forearms for the special .22 caliber 1894.



Early-style stocks fitted to later rifles:

Rifles produced after 1948 with serial numbers greater than 1,520,000 (approximate) will NOT accommodate early-style stocks due to changes in the upper receiver tang. After this serial number the tang was widened slightly on either side of the hammer. For these later production rifles we have developed a special Cowboy Shooter Retrofit buttstocks, which have the same styling and outside dimensions of early 1894 rifle carbine stocks, but with inletting to correctly work with later Model 94 receivers. These stocks are listed near the bottom of the page. Please be sure of your serial number and/or date of manufacture when ordering.

Also, please note changes in receiver and forearm designs which occurred in the 1950s. These important differences are explained for each forearm style listed below.

!
Larger picture

Winchester 1894 Straight Grip/Crescent Style Buttstock

For Winchester Model 1894 RIFLE (not carbine) models manufactured before 1938. Stocks for carbine models are listed elsewhere on this page.

To avoid mistakes in ordering and potential delays, please note the differences in styles between rifle and carbine stocks.

Larger picture

Winchester 1894 Pistol Grip/Crescent Style Buttstock

Issue style stock, as above, but for a pistol grip receiver. A pistol grip stock will not fit a straight grip receiver.

Larger picture

Cast Steel Crescent Buttplate, as-cast

For the DIY guy, these cast buttplates are in the rough and ready for your drilling, polishing, and bluing or case coloring. You will need professional grade polishing wheels and drill press for finishing.

Fits models Late 1873, Late 1885, Late 1886, 1890, 1892, 1894, 1895, as well as our Late 94 Cowboy Shooter Retrofit Stock.

Minor fitting is required whether for use on an original or a reproduced stock. Requires two screws which are available elsewhere on this page.

Winchester Buttplate Screws

A pair of blued screws of the proper size and configuration for Winchester rifle buttplates.
Larger picture

Winchester 1894 Straight Grip/Shotgun Style Buttstock, Large Buttplate

Early, larger-style; measures approximately 5-1/8" high x 1-5/8" wide at butt end.

Please be sure of your measurements when ordering stocks and buttplates.

Winchester 1894 Pistol Grip/Shotgun-Style Buttstock

Issue-style stock machined for original issue shotgun-style buttplate.

Buttplate area measures approximately 5-3/16" high X 1-3/4" wide. Machined for plain (no top spur) buttplate. The spur-type buttplate can be fitted to this stock with minor modification, as the two styles of buttplate have the same nominal dimensions and contours. The correct shotgun-style buttplates are listed below. A pistol grip stock will not fit a straight grip receiver.

Larger picture

Winchester Model 1894 Shotgun Style Buttplate, No Spur

Measures approximately 5-1/8" high x 1-11/16" wide.

Black plastic reproduced buttplate, checkered, with Winchester logo. Requires two screws which are available elsewhere on this page..

Larger picture

Winchester Shotgun Style Buttplate, With Spur

Measures approximately 5-1/8" high x 1-11/16" wide.

Black plastic reproduced buttplate, checkered, with Winchester logo. Requires two screws which are available elsewhere on this page.

Larger picture

Winchester Model 94 Straight Grip/Shotgun Style Buttstock, Small Buttplate

Later, smaller style; measures approximately 4-3/4" high and 1-7/16" wide at butt. Fitted to Model 94s produced from 1937 to 1948.

 Please be sure of your measurements when ordering stocks and buttplates.



Reproduced Plastic Shotgun Style Buttplate, Winchester Model 94

Reproduced plastic buttplate, smaller in size, for later (after 1937) shotgun-style buttstocks.

Larger picture

Winchester 1894 Rifle Forearm



These forearms are designed for early Winchester Model 1894 rifles with a U-shaped recess in the face of the receiver. They will not fit later Model 94 receivers with a round recess. This change in receiver and forearm design occurred in the mid-1950s. Please check your firearm to be certain of the style needed.

Takedown forearms: Takedown forearms are the same as standard rifle forearms with the exception of a slightly enlarged magazine tube hole at the rear. This is to allow clearance for the sleeve of the takedown assembly. Standard and takedown rifle forearms are identical in all other respects, including length.

We manufacture only standard rifle forearms, however, a standard rifle forearm may be customer-modified to accept the sleeve of the takedown assembly by increasing the hole diameter using a Dremel-type of rotary tool, or even a very sharp, small knife blade. Very little increase in hole diameter is needed and is not visible once the forearm is installed.

Larger picture

Winchester 1894 Carbine Buttstock

For early Winchester Model 1894 CARBINE (not rifle) models. Stocks for rifle models are listed elsewhere on this page.

Used on carbine models manufactured before 1938. This stock will fit all receivers up to serial number 1,520,000 (approximate).

NOT IN CURRENT INVENTORY. Available approximately November 22nd

To avoid mistakes in ordering and potential delays, please note the differences in styles between rifle and carbine stocks.

Larger picture

Winchester 1894 Carbine Forearm

These forearms are designed for earlier Winchester Model 1894 carbines with a U-shaped recess in the face of the receiver. They will not fit later Model 94 receivers with a round recess. This change in receiver and forearm design occurred in the mid-1950s. Please check your firearm to be certain of the style needed.

Forearm is held on with a band.

Beginning in 1950, with serial number 1,790,000 (approximate), forearms were shortened to 7-15/16". If your carbine falls within the time period of 1950 to the mid-1950s, and if you prefer the shortened version, you will need to cut the forward portion (beyond the barrel band) to match this shorter length; a simple modification.





Winchester Late Model 94 Shotgun-Style Stock

Winchester Late Model 94 Rifle Buttstock

Straight Grip/Shotgun Style Buttplate

For rifles manufactured after 1948 with serial numbers greater than 1,520,000 (approximate). Late Model 94 rifle stocks are NOT interchangeable with early 1894 stocks. Please be certain of your serial number and/or date of manufacture when ordering. This stock accommodates a recoil pad or our reproduced black plastic buttplate, listed above.

Winchester Late Model 94 (post-1964) Commemorative Rifle Buttstock

Issue-Style Straight Grip/Crescent Rifle Buttstock

Winchester issue-style buttstock, as furnished on a variety of post-1964 commemorative rifles. The stocks on these special-run rifles were fitted with stamped steel crescent buttplates, which fit only on the rear of the stock, with no return over the top of the stock. This commemorative stock is not compatible with an early original, or reproduced, Winchester 1894 crescent rifle buttplate with a top tang.

Many commemorative rifle buttstocks had a round medallion installed on the right side. Our replacement stocks are not inletted for these medallions, but they can be customer-modified by using a Forstner bit of the correct diameter. These bits leave a smooth, flat bottom within the drilled recess.

Please Select Barrel Style: Octagon Barrel Rifle Forearm (held on with a cap)

Winchester Late Model 94 Forearm

Order either the carbine (held on with a band, shown in photo) or octagon barrel rifle forearm (held on with a cap).

These forearms are designed for later Model 94 rifles and carbines with a round recess in the face of the receiver. They will not fit earlier Model 94 or 1894 receivers with a U-shaped recess. This change in receiver and forearm design occurred in the mid-1950s. Please check your firearm to be certain of the style needed.

Please note: Late Model 94 carbine forearms are available only for standard weight barrels, and are not compatible with Big Bore models. Standard weight carbine barrels have an approximate diameter of .930" at the receiver and .670" at the barrel band.

Post-1964 Commemorative Rifle Forearms: The Late Model 94 octagonal barrel rifle forearm is correct for most post-1964 commemorative rifles, however, certain commemorative models with shorter barrels utilized a shorter forearm. For these applications, this standard length forearm must be shortened (from the forward end) to the appropriate length.

Winchester Late Model 94 Early-Style Retrofit Rifle Stock

Winchester Late Model 94 Rifle-Style Cowboy Shooter Retrofit Buttstock

An authentic, early-style buttstock for later Model 94 rifles.
The outside contours and dimensions of this special retrofit stock are the same as those found on the earliest Winchester Model 1894 rifles. The inletting has been modified to fit the wider top receiver tangs of Model 94s manufactured after 1948, with serial numbers greater than 1,520,000 (approximate). Additional clearance has also been provided to accommodate the later coil-type of mainspring used on post-1964 models (will also work with earlier flat mainsprings). This stock will accept original Winchester Model 1894 crescent rifle buttplates as well as our reproduced Model 1894 buttplates.
Winchester Late Model 94 Early-Style Retrofit Carbine Stock

Winchester Late Model 94 Carbine-Style Cowboy Shooter Retrofit Buttstock

Early-style carbine buttstock for later Model 94 rifles.

DISCONTINUED ITEM due to unavailability of reproduced Winchester 1894 carbine buttplates. Price has been reduced. When they're gone, they're gone!

As with the retrofit rifle buttstock above, this early carbine-style stock has the same contours and dimensions as early-original, pre-WWII carbine stocks, but has the receiver tang inletting for later Model 94s, manufactured after 1948, with serial numbers greater than approximately 1,520,000. The widest portion of the upper receiver tangs on these later models is approximately one inch in width, as opposed to the narrower 7/8 inch width (approximate) of earlier rifles and carbines. This stock is manufactured to accept our reproduced Winchester Model 1894 carbine buttplate (no longer available), but will also work with early original Model 1894 carbine buttplates with slightly more fitting required.
Winchester Model 94 Early-Style Retrofit Carbine Forearm

Winchester Late Model 94 Cowboy Shooter Retrofit Carbine Forearm

A longer, early-style carbine forearm for your late Model 94.



This carbine forearm has the same dimensions as early-original Model 1894 forearms, but is machined to fit later Model 94 receivers which utilize a round recess in the face of the receiver, rather than the earlier U-shaped recess. This change occurred in the mid-1950s and continued until the end of production. If you prefer the authentic look of the earlier, longer carbine forearm for your later Model 94, this forearm is for you! Please note: Late Model 94 Cowboy Shooter Retrofit carbine forearms are available only for standard weight barrels, and are not compatible with Big Bore models. Standard weight carbine barrels have an approximate diameter of .930" at the receiver and .670" at the barrel band.
Deluxe Stock Finishing Kit

Stock Finishing Kits

Convenient in-a-box supplies for fitting and finishing stocks. Save money by ordering the kit!

We offer two stock finishing kits. The Standard Kit consists of inletting black, three grits of sandpaper, filler/sealer, PGW Classic Oil Finish, neutral colored gunstock wax, a green "Scotch-Brite" pad (replaces steel wool), polishing cloth, and brushes. Our Deluxe Kit adds a straight file, a half round file, and straight and curved hand gouges -- everything you need to properly fit and finish stocks at a savings over buying the products individually, in one handy box. The Standard Kit is $28.50; the Deluxe Kit is $47.50.
